drilling machine
Qun Ho
Contact person
Basic Information
| Place of Origin | Jiangsu China (Mainland) |
|---|---|
| Brand Name | GUOQUAN |
| Model Number | BJK65 |
drilling machine Technical parameter: MODEL : BJK65 Distance between bits : 32mm Quantity of horizontal boring box : 1 (one motor with 21 bits) Quantity ofvertical boring box : 2×2 (1 motor with11 bits)Quantity of bits : 65pcs Max panel diameter : Φ35mm Max panel thickness : 60mm Max panel width : 1750mm Max panel length : 2800mm Power : 6KW/380V/50HZPneumatic power : 0.6-08MPa Machine Size : L2850×W2800×H1600mm Main characteristic:1), It has high precision double guide lines and pneumatic locking system, boring body can move easily and agile .2), Vertical box is combined by two separates box, each can rotate from 0-90, drill in large scope .3), Position fixed quickly in horizontal and vertical forward, high pression in drilling holes .4), It beautiful in outlook, and got many patents .5), It economic in using, and widely welcomed .
Delivery terms and packaging
Packaging Detail: pallet+palstic cover Delivery Detail: 25 days
Port: nantong or shanghai port
